Hi-tech solutions
to coat PVC
to coat PVC
Aesthetically advanced coatings
to protect PVC
to protect PVC
PVC is one of the most widespread plastic material. Thanks to its versatility, it is used in several fields: from buildings to packaging, from furniture to fashion accessories.
One of the areas of greater ferment is the living environment, in terms of production of items, such as windows, frames, roller shutters, verandas, doors, garage doors, claddings, fences and indoor dividing barriers.
After many years of research and development, the chemical-mechanical features achieved by PVC technology have become a standard.
Water-based Rennerplast coating systems have improved PVC manufacturing to the highest level, guaranteeing high aesthetical performances, able
to resist up to 15 years to atmospheric agents.
One of the areas of greater ferment is the living environment, in terms of production of items, such as windows, frames, roller shutters, verandas, doors, garage doors, claddings, fences and indoor dividing barriers.
After many years of research and development, the chemical-mechanical features achieved by PVC technology have become a standard.
Water-based Rennerplast coating systems have improved PVC manufacturing to the highest level, guaranteeing high aesthetical performances, able
to resist up to 15 years to atmospheric agents.
Shutters
Claddings
Dividing barriers
Frames
Windows
Roller shutters
Doors
Garage doors
Four instant advantages
Thanks to their exclusive composition,
developed by Renner laboratories,
Rennerplast coatings ensure
immediate advantages.
developed by Renner laboratories,
Rennerplast coatings ensure
immediate advantages.
Durability
Up to 15 years of warranty
Up to 15 years Warranty certifies the extraordinary Renneplast coatings resistance. Protected by Rennerplast products, windows frames, roller shutters, verandas, doors, garage doors, claddings, fances are protected against the attacks of atmospheric agents and pollution, thus reaching unprecedented durability.
Design
Endless colors and special effects
With Rennerplast range, designers, architects, interior designers, customers, etc. can set their creativity free, mixing all shades and effects. Pastel colors, metallic tones, matt and semi-matt finishes, textured topcoat, etc. No limits to imagination.
Speed
More efficiency during production
Rennerplast coating system is based on just one product which is applicable in one single coat: a synonym of speed. Super adhesion and speed
of drying drastically reduce production times and costs.
of drying drastically reduce production times and costs.
Health
Less VOC in the air
Rennerplast water-based coatings, like all the other water-based products created by Renner laboratories, respect both nature and people. Our chemists are aware of the important role of the industry in the fight against global warming; they eliminated 95% of solvent emissions. Our water-based coatings ensure very low VOC emissions and do not contain harmful substances to man and nature. All this to create healthier and more livable spaces and to participate to material and energy savings.
Strengths
of Rennerplast coatings
of Rennerplast coatings
Solutions
for the technician
for the technician
Application by spray
Hand or automatic spray, either airless or airmix
|
1k coating YO M377 in its white and neutral version |
2k coating YO M977 in its white, neutral and clear version |
|
1k coating YO M376 formulated with raw materials compliant with US and Canadian markets regulations and certifications |
|
|
1k textured coating YO M379 in two different grains (fine and medium) |
2k textured coating YO M979 in two different grains (fine and medium) |
Vacuum application
|
1k coating YO M372 in its white and neutral version |
|
1k textured coating YO M362 in two different grains (fine and medium) |
|
In two simple steps, Rennerplast finish looks perfect. |
High-definition colour results
Thanks to Renner Italia’s tintometric Color System, Rennerplast offers many advantages:
of the color, by means of volumetric dosing machines
or neutral bases and adding colored pastes
To facilitate the color preparation, Rennerplast is available
in two different versions for each converter:
in two different versions for each converter:
NTR or neutral: for the preparation of dark colours
SBN or white: for the preparation of light colours
The tintometric system can accurately reproduce all the shades of RAL, NCS, CS and Chroma colour charts, thus offering trendy colour solutions which can satisfy every aesthetic need (textures, two-tone colours, special finishes, aluminium effects etc.)
The compared certifications
| AAMA 615-17 | ||
| Voluntary Specification, Performance Requirements and Test Procedures for Superior Performing Organic Coatings on Plastic Profiles | ||
| Rennerplast 1k: YO xxM376 | ||
| 7.1 | Color uniformity | √ |
| 7.2 | Specular Gloss | √ |
| 7.3 | Dry film hardness | √ |
| 7.4 | Film adhesion | |
| Dry adhesion | √ | |
| Wet adhesion | √ | |
| Boiling water adhesion | √ | |
| 7.5 | Impact resistance | √ |
| 7.6 | Abrasion resistance | √ |
| 7.7 | Chemical resistance | |
| 7.7.1 | Muratic acid (HCl) resistance | √ |
| 7.7.2 | Mortar resistance | √ |
| 7.7.3 | Nitric acid (HNO3) resistance | √ |
| 7.7.4 | Detergent resistance | √ |
| 7.8 | Humidity resistance | √ |
| 7.10 | Heat shock resistance | √ |
| 7.11 | Stability to high temperatures and humidity | √ |
| 7.12 | Heat build-up | √ |
| Qualité Batiment QB 33 | ||
| Coated PVC Profiles – Coating Products – Lacquers | ||
| Rennerplast 2K: YO xxM977 – YO xxM979 | ||
| 1.3.1 | Thickness of dry coating film | √ |
| 1.3.2 | Polymerisation of the coating (Resistance to MEK) | √ |
| 1.3.3 | Pencil hardness | √ |
| 1.3.4 | Mortar resistance | √ |
| 1.3.5 | Impact resistance | √ |
| 1.3.6 | Grid adhesion | √ |
| 1.4.1 | Artificial aging (xenon lamp) | |
| Base colours (3000 h)* | √ | |
| Secondary colours (1500 h)** | √ | |
| 1.4.2 | Heat shock resistance | √ |
| *Base colors:: group 1: mineral pigments (e.g. RAL 1013); group 2: mineral and organic pigments (e.g. RAL 7016); group 3: organic pigments (e.g. RAL 3005); group 4: metallic pigments (e.g. RAL 9006) |
| **Secondary colors:: group 5: medium (e.g. RAL 7005); group 6: bright (e.g. RAL 1015); group 7: dark (e.g. RAL 8019); group 8: blue (e.g. RAL 5015); group 9: orange – yellow (e.g. RAL 2010); group 11: green (e.g. RAL 6017) |
| Quality Assurance RAL-GZ 716 | ||
| Quality and Test Requirements for window profiles made from PVC-U: Technical Appendix 4.5 “Section I”, part 5: Coated profiles |
||
| Rennerplast 1k: YO xxM377 Rennerplast 2k: YO xxM977 |
||
| 2.2.14.1 | Fastness after artificial weathering | |
| Climate zone M (8 GJ/m2) | ||
| Visual evaluation | √ | |
| Colourimetric evaluation | √ | |
| Climate zone S (12 GJ/m2) | ||
| Visual evaluation | √ | |
| Colourimetric evaluation | √ | |
| 2.2.14.2 | Resistance to weathering after artificial weathering | |
| Climate zone M (8 GJ/m2) | ||
| Charpy Impact | √ | |
| Adhesion | √ | |
| Climate zone S (12 GJ/m2) | ||
| Charpy Impact | √ | |
| Adhesion | √ | |
| part IIa3 | Heat build-up | √ |
Why to choose
the coating instead of film
the coating instead of film
COATING
- Lighter warehouse
- Small production batches
- Even covering of all the surface
- Ultra-fast corrections
- Lower average costs
- Big stockpiles in warehouse, with risk of expiry
- Wastes of material in small batches
- Partial covering of the object
- Time consuming corrections
- Higher average costs
FILM
COATING
FILM
Lighter warehouse
Big stockpiles in warehouse,
with risk of expiry
with risk of expiry
Small production batches
Wastes of material in small batches
Even covering of all the surface
Partial covering of the object
Ultra-fast corrections
Time consuming corrections
Lower average costs
Higher average costs
COATING
FILM
Hi-tech research
company
company
Rennerplast coatings can satisfy any aesthetic and performance need because they have been created inside Renner laboratories. Our chemists work closely with doors and windows manufacturers, as well as with the most qualified producers of professional coating machinery. Renner researchers analyze and test innovative products, especially in the complex field of water-based and UV curing coatings.
The company is equipped with the most modern analytical instruments for the formulation of resins and coatings.
The company is equipped with the most modern analytical instruments for the formulation of resins and coatings.
